Avlink 43 inch Waterproof Portable Outdoor LCD Kiosk Battery Powered Key Feature
Built-in 62000mAh battery for 18 hours working
Optical bonding technology, makes the screen more clear and beautiful
High Tni industrial panel for outdoor sunlight directly readable
Optional 10 points touch screen for interactive
Portable design for movable application, suitable for stores and coffees advertising
| Model | AVL-OD430 |
|---|---|
| Size | 43inch |
| Resolution | 1920*1080 |
| Touch | Capacitive touch screen |
| Color | Black, RAL color option, White |
| Operating system | Android 9/11/13/14, HDMI input, Windows 10/11 Pro |
| Application | Outdoor |
| Production Time | 20-25 days |
43 inch Waterproof Portable Outdoor LCD Kiosk Battery Powered, high brightness 2500nits, 62000mAh battery to work for 18 hours, touch screen digital signage
I. Optical Bonding Technology Introduction:
Avlink 43inch outdoor screen is using optical bonding technology, which is a process that uses liquid optically clear adhesive (LOCA) or optical gel to precisely bond the touch panel (or cover glass) to the display module. This technique significantly improves the optical performance of the display while also enhancing its durability and reliability.
During the full lamination process, an optical-grade adhesive is applied to fully bond the cover glass to the surface of the display panel, eliminating the air gap typically found between the touch layer and the screen. By removing this air gap, the number of internal reflective surfaces is reduced, allowing more light to transmit through and minimizing unwanted reflections. As a result, the display’s optical characteristics—such as light transmittance, color contrast, and clarity—are greatly enhanced. This leads to improved readability, especially under bright lighting conditions, offering a more vivid and comfortable viewing experience.
| Specifications | |||
| TFT Panel | |||
| Model No. | AVL-OD430OB | ||
| Panel size | 43inch TFT-LCD | ||
| Display area(mm)/mode | 941(H)*529(V) | ||
| Maximum resolution | 1920*1080 | ||
| Display color | 16.7M | ||
| Brightness (nits) default | 1500nits Working Time 18 hours | ||
| Brightness (nits) optional | 2000nits Working Time 15 hours | ||
| Brightness (nits) optional | 2500nits Working Time 12 hours | ||
| Contrast | 3000:1 | ||
| Visual angle | 178°/178° | ||
| Response time | 6ms | ||
| Life(hrs) | >60,000(hrs) | ||
| Touch | Multipoint capacitive touch screen optional | ||
| Interface | HDMI, RJ-45, USB, VGA, WIFI (optional) | ||
| Operating system | |||
| Media Formats | Video (MPG, AVI, MP4, RM, RMVB, TS), Audio (MP3, WMA), Image(JPG, GIF, BMP, PNG) | ||
| Media resolution | 1080*1920, (Downward compatibility) | ||
| Operating system | Android 9.0 | ||
| CPU | T972 | ||
| RAM | 2GB DDR4 | ||
| ROM | 16GB NAND | ||
| GPU | MALI-G51 MP2，support FULL HDR | ||
| USB | USB2.0 HOST (x2) | ||
| LAN | 10/100M Ethernet | ||
| Wi-Fi | 802.11b/g/n | ||
| Speaker | 8Ω 5W x2 | ||
| Battery | |||
| Battery Technology | It adopts outdoor lithium iron phosphate battery, which has better life, higher temperature resistance and high safety factor. | ||
| Charging Time | 8 hours | ||
| Working Time | 15 hours | ||
| Battery Capacity | 62000mAh | ||
| Power Supply | 24V | ||
| Power Consumption | 58W~110W(Automatic photosensitive power consumption is a variable value) | ||
| Appearance | |||
| Material | Aluminium + Galvanized steel | ||
| Color | Black, white | ||
| Dimension(L*W*D)mm | 1244*615*186 | ||
| Package size | 1510*370*800 | ||
| Footpint | 604.7*478 | ||
| Net Weight | 59kg | ||
| Gross Weight | 61kg | ||
| Electricity | |||
| Power supply | AC100~240V 50 /60 HZ | ||
| Power termination | Integrated circuit breaker | ||
| Ambient light sensor | Yes | ||
| Antenna | Yes | ||
| Accessibility | Vandal proof security key access | ||
| Temperature | |||
| Working temperature | -20℃～70℃ | ||
| Storage temperature | -30℃~80℃ | ||
| Working humidity | 10-80% | ||
| Storage humidity | 5-95% | ||
| Accessories | Remote Controller, User Manual, Charger, Power Cable | ||
