AVLink 22 inch Spatial Signage – Immersive Reality Commercial Display
| Model | AVL-ID215 |
|---|---|
| Size | 13.3inch, 15.6inch, 22inch, 32inch, 86inch |
| Resolution | 1920*1080, 3840*2160 |
| Touch | Capacitive touch screen |
| Operating system | Android 9/11/13/14, HDMI input, Windows 10/11 Pro |
| Color | RAL color option |
| Application | Indoor |
| Production Time | 3-5 days |
| Options | Brand logo |
AVLink 22 inch Spatial Signage – Immersive Reality Commercial Display, slim thickness 20mm, creates immersive authentic visuals with innovative display
Immersive 3D Display – Bring your brand into reality
Achieves lifelike visual experience via cutting-edge display technology
Embark on a new era of commercial display. Crafted to deliver an ultimate immersive visual journey, spatial signage makes a powerful visual impact across diverse scenarios. Boasting stunning 3D visuals, ultra-slim streamlined design and flawless content sync, it creates remarkable and memorable viewing experiences.
Deliver immersive realism with innovative display technology
Bring your content to vivid 3D life and connect closely with your audience.
Exquisitely lifelike details feel tangible, leaving every viewing moment deeply memorable.
Bold visuals, seamless fitting.
Ultra-thin Design
Boasting a slim 2-inch body yet stunning 3D visuals, it features easy installation just like conventional signage. Lightweight and space-saving, it adapts perfectly to diverse scenarios.
| Specifications | |||
| TFT Panel | |||
| Model | AVL-ID220SS | ||
| Panel size | 22inch | ||
| Resolution | 1080*1920 (9:16) | ||
| Brightness (nits) | 300nits | ||
| Orientation | Portrait | ||
| Contrast Ratio(Typ.) | 4000:1 | ||
| Active Display Area | 699.8(H) × 395.1(V) | ||
| Operation Hour | 24/7 | ||
| Display color | 16.7M | ||
| Visual angle | 178°/178° | ||
| Response time | <6.5ms | ||
| Touch | PCAP touch optional | ||
| Operating system | |||
| Operating system | Android | ||
| RAM | 2G/4G | ||
| ROM | 32G/64G | ||
| Input | HDMI*2, USB2.0*2, RJ45, TF card | ||
| HDMI input | 480i, 480p, 576i, 576p, 720p,1080i, 1080P, 2160p | ||
| USB | USB*1 | ||
| Output | Stereo mini Jack | ||
| Headphone Jack | 3.5mm headphone jack, one dual-channel speaker output port. | ||
| Speaker | 5W*2 | ||
| Appearance | |||
| Enclosure color | Grey/Black, customized RAL | ||
| Enclosure material | Aluminum Alloy / Metal | ||
| Dimension(L*W*D)mm | 512*308*48mm | ||
| Package dimension | 566*96*368mm | ||
| Weight | Screen 4.4kg, desktop bracket: 2kg | ||
| Gross weight | 6.4kg | ||
| Vesa mount | 100*100 | ||
| Bezel width (mm) | 20mm | ||
| Electricity | |||
| Power supply | AC100~240V 50 /60 HZ | ||
| Maximum power consumption | <50W | ||
| Temperature | |||
| Working temperature | 0℃～40℃ | ||
| Storage temperature | -10℃~60℃ | ||
| Working humidity | 85% | ||
| Storage humidity | 85% | ||
| Accessories include | Quick Setup Guide, Warranty Card, Power Cord, Remote Controller (no batteries), wall bracket | ||
Avlink 22 inch Spatial Signage :
About AVLink:
Shenzhen Avlink Technology Co., Ltd – Your Trusted Digital Signage Partner
Shenzhen Avlink Technology is a leading manufacturer specializing in high-quality digital signage and innovative display solutions. With a 4,000-square-meter factory and a dedicated R&D team of 6 experts, we deliver customized digital display screens tailored to your unique needs—providing design drawings within just 1 day.
Comprehensive Product Range – Offering 1,000+ digital advertising screens, including:
Fast Production & Global Reach
3 days lead time for quick delivery
10+ years of export experience, shipping to 70+ countries
Certified with COO, CE-LVDS, CE-EMC, FCC, RoHS, CSA, and KC, SGS, Bureau Veritas
End-to-End Support
On-site installation services for seamless deployment, available in Israel, Italy, France, Netherlands, Germany, Sweden, Switzerland, USA, Canada, Mexico, Oman, Dubai, China Macau, China Hong Kong etc.
24/7 after-sales support to ensure uninterrupted operation
Avlink combines cutting-edge technology, rapid production, and reliable service to power your digital advertising screens with excellence
